Manufacturer No:

2N7002TQ-7-F

Manufacturer:

DIODES

Package:

SOT-523

Description:

MOSFET (Metal Oxide) N-Channel Tape & Reel (TR) 13.5 ? @ 500mA, 10V ±20V 50pF @ 25V 60V SOT-523

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

2N7002TQ-7-F information

DIODES 2N7002TQ-7-F technical specifications, attributes, parameters and parts with similar specifications to DIODES 2N7002TQ-7-F.

  • Type
  • Parameter
  • Factory Lead Time
  • 14 Weeks
  • Mount
  • Surface Mount
  • Mounting Type
  • Surface Mount
  • Package / Case
  • SOT-523
  • Transistor Element Material
  • SILICON
  • Operating Temperature
  • -55°C~150°C TJ
  • Packaging
  • Tape & Reel (TR)
  • Series
  • Automotive, AEC-Q101
  • Published
  • 2012
  • JESD-609 Code
  • e3
  • Pbfree Code
  • yes
  • Part Status
  • Active
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • Number of Terminations
  • 3
  • ECCN Code
  • EAR99
  • Terminal Finish
  • Matte Tin (Sn)
  • Additional Feature
  • HIGH RELIABILITY
  • Subcategory
  • FET General Purpose Power
  • Technology
  • MOSFET (Metal Oxide)
  • Terminal Position
  • DUAL
  • Terminal Form
  • GULL WING
  • Peak Reflow Temperature (Cel)
  • 260
  • Time@Peak Reflow Temperature-Max (s)
  • 40
  • JESD-30 Code
  • R-PDSO-G3
  • Configuration
  • SINGLE WITH BUILT-IN DIODE
  • Power Dissipation-Max
  • 150mW Ta
  • Operating Mode
  • ENHANCEMENT MODE
  • FET Type
  • N-Channel
  • Transistor Application
  • SWITCHING
  • Rds On (Max) @ Id, Vgs
  • 13.5 ? @ 500mA, 10V
  • Input Capacitance (Ciss) (Max) @ Vds
  • 50pF @ 25V
  • Current - Continuous Drain (Id) @ 25°C
  • 115mA Ta
  • Drain to Source Voltage (Vdss)
  • 60V
  • Drive Voltage (Max Rds On,Min Rds On)
  • 5V 10V
  • Vgs (Max)
  • ±20V
  • Continuous Drain Current (ID)
  • 115mA
  • Drain Current-Max (Abs) (ID)
  • 0.115A
  • DS Breakdown Voltage-Min
  • 60V
  • Feedback Cap-Max (Crss)
  • 5 pF
  • RoHS Status
  • RoHS Compliant

Download datasheets and manufacturer documentation for DIODES 2N7002TQ-7-F.

Datasheets:

Environmental Information:

2N7002TQ-7-F Overview


As an op amp's input capacitance parameter, CI, is defined as the capacitance between the input terminals when one input is grounded, this device's maximum input capacitance is 50pF @ 25V.This device conducts a continuous drain current (ID) of 115mA, which is the maximum continuous current transistor can conduct.The drain current is the maximum continuous current this device can conduct, which is 0.115A.A normal operation of the DS requires keeping the breakdown voltage above 60V.This transistor requires a drain-source voltage (Vdss) of 60V.In order to reduce power consumption, this device uses a drive voltage of 5V 10V volts (5V 10V).

2N7002TQ-7-F Features


a continuous drain current (ID) of 115mA
a 60V drain to source voltage (Vdss)


2N7002TQ-7-F Applications


There are a lot of Diodes Incorporated
2N7002TQ-7-F applications of single MOSFETs transistors.


  • Motor drives and Uninterruptible Power Supplies
  • Micro Solar Inverter
  • DC/DC converters
  • Power Tools
  • Motor Drives and Uninterruptible Power Supples
  • Synchronous Rectification
  • Battery Protection Circuit
  • Telecom 1 Sever Power Supplies
  • Industrial Power Supplies
  • PFC stages, hard switching PWM stages and resonant switching
