Manufacturer No:

3046L-1-502

Manufacturer:

BOURNS

Package:

Module, Wire Leads, Threaded

Description:

For Measuring Linear Position Wire Leads Round Shaft -55°C~125°C ±5% Module, Wire Leads, Threaded

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

3046L-1-502 information

BOURNS 3046L-1-502 technical specifications, attributes, parameters and parts with similar specifications to BOURNS 3046L-1-502.

  • Type
  • Parameter
  • Factory Lead Time
  • 11 Weeks
  • Contact Plating
  • Silver
  • Mount
  • Chassis Mount
  • Mounting Type
  • Chassis Mount
  • Package / Case
  • Module, Wire Leads, Threaded
  • Operating Temperature
  • -55°C~125°C
  • Packaging
  • Bulk
  • Published
  • 2004
  • Tolerance
  • 20%
  • Part Status
  • Active
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • Termination
  • Lead Wire
  • ECCN Code
  • EAR99
  • Temperature Coefficient
  • -10001000 ppm/°C
  • Resistance
  • 5kOhm
  • Composition
  • Potentiometer
  • HTS Code
  • 8533.40.80.70
  • Power Rating
  • 125mW
  • Technology
  • Resistive
  • Depth
  • 5.69mm
  • Construction
  • Sealed
  • Base Part Number
  • 3046L
  • Military Standard
  • Not
  • Termination Style
  • Wire Leads
  • Actuator Type
  • Round Shaft
  • Size Code
  • 7726
  • Taper
  • Linear
  • Linearity
  • ±5%
  • Resistance Tolerance
  • ±20%
  • For Measuring
  • Linear Position
  • Linear Range
  • 0 ~ 3.81mm (0 ~ 0.15)
  • Length
  • 40.41mm
  • RoHS Status
  • RoHS Compliant

Download datasheets and manufacturer documentation for BOURNS 3046L-1-502.

Datasheets:

PCN Other:

ConflictMineralStatement:

3046L-1-502 Overview


As a measure of protection, the linear position measuring sensors are housed in Module, Wire Leads, Threaded packages. There is an electronic component packaged in the Bulk. Sensors for linear position measuring can oppose the passage of currents that are 5kOhm. ldeally, linear position measuring sensors dissipate 0.125W power.

3046L-1-502 Features


Operating Temperature: -55°C~125°C
Mount: Chassis Mount
Package / Case: Module, Wire Leads, Threaded
Mounting Type: Chassis Mount
Linear Range: 0 ~ 3.81mm (0 ~ 0.15)
Resistance Tolerance: ±20%


3046L-1-502 Applications


There are a lot of Bourns Inc.
3046L-1-502 Angle & Linear Position Measuring Sensors applications.


  • Medical robots and fitness equipment
  • Absolute Rotary Position Sensor
  • Steering Wheel Position Sensor
  • Pedal Position Sensor
  • Motor-shaft Position Sensor
  • Throttle Position Sensor
  • Float-Level Sensor
  • Ride Height Position Sensor
  • Non-Contacting Potentiometer
  • X, Y, Z stage position feedback
