Manufacturer No:

5650118-1

Manufacturer:

TE Connectivity

Package:

Description:

Female Black 0.100 2.54mm Phosphor Bronze 2 Rows Tray Solder Gold 30 Positions Polyester, Glass Filled

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

5650118-1 information

TE Connectivity 5650118-1 technical specifications, attributes, parameters and parts with similar specifications to TE Connectivity 5650118-1.

  • Type
  • Parameter
  • Lifecycle Status
  • ACTIVE (Last Updated: 4 days ago)
  • Factory Lead Time
  • 11 Weeks
  • Contact Material
  • Phosphor Bronze
  • Contact Plating
  • Tin, Gold
  • Mount
  • Through Hole
  • Mounting Type
  • Through Hole, Right Angle
  • Housing Material
  • Polyester
  • Material - Insulation
  • Polyester, Glass Filled
  • PCB Mounting Orientation
  • Right Angle
  • Underplate Material
  • Nickel
  • Operating Temperature
  • -55°C~ 85°C
  • Packaging
  • Tray
  • Series
  • Standard Edge II
  • Published
  • 2004
  • Part Status
  • Active
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • Termination
  • Solder
  • Connector Type
  • Socket
  • Number of Positions
  • 30
  • Max Operating Temperature
  • 85°C
  • Min Operating Temperature
  • -55°C
  • Color
  • Black
  • Number of Rows
  • 2
  • Gender
  • Female
  • Pitch
  • 0.100 2.54mm
  • Orientation
  • Right Angle
  • Contact Finish
  • Gold
  • Number of Contacts
  • 30
  • Housing Color
  • Black
  • Operating Supply Voltage
  • 400V
  • Card Type
  • Non Specified - Dual Edge
  • Read Out
  • Dual
  • ELV
  • Compliant
  • Max Current Rating
  • 3A
  • Plating
  • Gold
  • Contact Current Rating
  • 3A
  • Circuit Application
  • Power
  • Number of Power Positions
  • 30
  • Height
  • 17.018mm
  • Contact Finish Thickness
  • 30.0?in 0.76?m
  • Plating Thickness
  • 760 nm
  • Card Thickness
  • 0.054 ~ 0.070 1.37mm ~ 1.78mm
  • RoHS Status
  • RoHS Compliant
  • Flammability Rating
  • UL94 V-0

Download datasheets and manufacturer documentation for TE Connectivity 5650118-1.

Datasheets:

5650118-1 Overview


The material was packaged in accordance with the specifications provided by Tray.You should mount it with type Through Hole, Right Angle.Connecting the device to the connector socket Socket is the method used by the device.In the Standard Edge II field, the series of the device is indicated.An operating temperature of [0°C] ensures stable operation.The device must be kept at a temperature of -55°C degrees Celsius in order to be reliable.
