MOLEX 87832-0420

Manufacturer No:

87832-0420

Manufacturer:

Package:

Description:

Board Connector, 4 Contact(s), 2 Row(s), Male, Straight, 0.079 inch Pitch, Surface Mount Terminal, Locking, Black Insulator, Receptacle,

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

87832-0420 information

MOLEX 87832-0420 technical specifications, attributes, parameters and parts with similar specifications to MOLEX 87832-0420.

Type
Parameter

Pbfree Code
Yes

RoHS Status
RoHS Compliant

Part Life Cycle Code
Active

Ihs Manufacturer
MOLEX LLC

Reach Compliance Code
compliant

ECCN Code
EAR99

HTS Code
8536.69.40.40

Samacsys Manufacturer
Molex

Additional Feature
TUBE PACKAGE

Body Breadth
0.248 inch

Body Depth
0.299 inch

Body Length
0.262 inch

Body/Shell Style
RECEPTACLE

Connector Type
BOARD CONNECTOR

Contact Finish Mating
NOT SPECIFIED

Contact Finish Termination
MATTE TIN OVER NICKEL

Contact Gender
MALE

Contact Material
NOT SPECIFIED

Contact Pattern
RECTANGULAR

Contact Style
SQ PIN-SKT

DIN Conformance
NO

Dielectric Withstanding Voltage
1400VAC V

Filter Feature
NO

IEC Conformance
NO

Insulation Resistance
1000000000 Ω

Insulator Color
BLACK

Insulator Material
GLASS FILLED POLYAMIDE

JESD-609 Code
e3

MIL Conformance
NO

Mating Contact Pitch
0.079 inch

Mating Contact Row Spacing
0.079 inch

Mating Information
MULTIPLE MATING PARTS AVAILABLE

Mixed Contacts
NO

Mounting Option 1
LOCKING

Mounting Style
STRAIGHT

Mounting Type
BOARD

Number Of Connectors
ONE

Number Of PCB Rows
2

Number of Rows Loaded
2

Operating Temperature-Max
105 °C

Operating Temperature-Min
-55 °C

Option
GENERAL PURPOSE

PCB Contact Pattern
RECTANGULAR

Plating Thickness
15u inch

Rated Current (Signal)
2 A

Reference Standard
UL, CSA

Terminal Pitch
2 mm

Download datasheets and manufacturer documentation for MOLEX 87832-0420.

Datasheets:

molex-878320420-datasheets-8531.pdf

molex-878320420-datasheets-8537.pdf

87832-0420 Overview

Packaging is in the form of Male Pin.Other features include TUBE PACKAGE, to name just a few.If the temperature is below 105°C, it's best to use it.-55°C is the minimum temperature for this device.There is a mounting hole at Surface Mount.

87832-0420 Features

87832-0420 Applications

There are a lot of Molex
87832-0420 Rectangular Connectors applications.

Embedded systems
Datacom
Communication
Medical technology
Military Technology
Measuring & Control Technology
Instrumentation
Automotive Electronics
Telecommunications
Data Technology
