ADSP-CM409CBCZ-AF information

ADI ADSP-CM409CBCZ-AF technical specifications, attributes, parameters and parts with similar specifications to ADI ADSP-CM409CBCZ-AF.

  • Type
  • Parameter
  • Lifecycle Status
  • CONTACT ADI (Last Updated: 3 weeks ago)
  • Factory Lead Time
  • 14 Weeks
  • Mount
  • Surface Mount
  • Mounting Type
  • Surface Mount
  • Package / Case
  • 212-LBGA, CSPBGA
  • Number of Pins
  • 212
  • Operating Temperature
  • -40°C~105°C TA
  • Packaging
  • Tray
  • Pbfree Code
  • no
  • Part Status
  • Active
  • Moisture Sensitivity Level (MSL)
  • 3 (168 Hours)
  • Number of Terminations
  • 212
  • Type
  • Floating Point
  • Technology
  • CMOS
  • Terminal Position
  • BOTTOM
  • Terminal Form
  • BALL
  • Peak Reflow Temperature (Cel)
  • 260
  • Supply Voltage
  • 3.3V
  • Terminal Pitch
  • 1mm
  • Frequency
  • 240MHz
  • Time@Peak Reflow Temperature-Max (s)
  • 30
  • Pin Count
  • 212
  • Operating Supply Voltage
  • 3.3V
  • Interface
  • CAN, Ethernet, I2C, SPI, SPORT, UART/USART, USB
  • Min Supply Voltage
  • 3.13V
  • Memory Size
  • 2MB
  • Number of I/O
  • 91
  • RAM Size
  • 48kB
  • Number of Bits
  • 32
  • Bit Size
  • 32
  • Data Bus Width
  • 32b
  • Address Bus Width
  • 24
  • Density
  • 16 Mb
  • Boundary Scan
  • YES
  • Low Power Mode
  • YES
  • Integrated Cache
  • YES
  • Voltage - I/O
  • 3.30V
  • Number of UART Channels
  • 3
  • Non-Volatile Memory
  • FLASH (2MB)
  • Voltage - Core
  • 1.20V
  • On Chip Data RAM
  • 384kB
  • Length
  • 19mm
  • Height Seated (Max)
  • 1.7mm
  • REACH SVHC
  • No SVHC
  • RoHS Status
  • RoHS Compliant
  • Lead Free
  • Contains Lead

Download datasheets and manufacturer documentation for ADI ADSP-CM409CBCZ-AF.

Datasheets:

ConflictMineralStatement:

ADSP-CM409CBCZ-AF Overview


In electronic terms, it is a type of component that comes in the package of type 212-LBGA, CSPBGA .Tray is the packaging method provided.Due to its Floating Point membership, it is ideal for a wide range of applications.The mounting of the device is done in the direction of Surface Mount.As long as it is operated at the temperature of -40°C~105°C TA, it will operate normally.3.30V refers to the range of analog voltages that can be input or output.212 terminations are available for its use.3.3V is the supply voltage.212 component pins are present.Its configuration includes 212 pins.The device is specifically designed to operate at the frequency of 240MHz.As a mounting method, it uses Surface Mount.This device requires a minimum voltage of 3.13V.This device can handle a maximum voltage of 3.47V.This device is powered by 3.3V's supply voltage.2MB data can be stored in the memory of this device.Data format and transmission speed are configurable on 3 UART channels for asynchronous serial communication.There are 91 I/Os on the device.The device stores 32 pieces of information.
