INFINEON AUIRF7769L2TR
INFINEON AUIRF7769L2TR

INFINEON AUIRF7769L2TR

Manufacturer No:

AUIRF7769L2TR

Manufacturer:

INFINEON

Package:

DirectFET? Isometric L8

Description:

MOSFET (Metal Oxide) N-Channel Tape & Reel (TR) 3.5m ? @ 74A, 10V ±20V 11560pF @ 25V 300nC @ 10V 100V DirectFET? Isometric L8

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

AUIRF7769L2TR information

INFINEON AUIRF7769L2TR technical specifications, attributes, parameters and parts with similar specifications to INFINEON AUIRF7769L2TR.

  • Type
  • Parameter
  • Factory Lead Time
  • 16 Weeks
  • Mount
  • Surface Mount
  • Mounting Type
  • Surface Mount
  • Package / Case
  • DirectFET? Isometric L8
  • Number of Pins
  • 15
  • Transistor Element Material
  • SILICON
  • Operating Temperature
  • -55°C~175°C TJ
  • Packaging
  • Tape & Reel (TR)
  • Series
  • HEXFET®
  • Published
  • 2015
  • Part Status
  • Active
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • Number of Terminations
  • 9
  • ECCN Code
  • EAR99
  • Technology
  • MOSFET (Metal Oxide)
  • Terminal Position
  • BOTTOM
  • Terminal Form
  • NO LEAD
  • Peak Reflow Temperature (Cel)
  • NOT SPECIFIED
  • Time@Peak Reflow Temperature-Max (s)
  • NOT SPECIFIED
  • Reference Standard
  • AEC-Q101
  • JESD-30 Code
  • R-XBCC-N9
  • Number of Elements
  • 1
  • Configuration
  • SINGLE WITH BUILT-IN DIODE
  • Power Dissipation-Max
  • 3.3W Ta 125W Tc
  • Case Connection
  • DRAIN
  • FET Type
  • N-Channel
  • Transistor Application
  • SWITCHING
  • Rds On (Max) @ Id, Vgs
  • 3.5m ? @ 74A, 10V
  • Vgs(th) (Max) @ Id
  • 4V @ 250?A
  • Input Capacitance (Ciss) (Max) @ Vds
  • 11560pF @ 25V
  • Current - Continuous Drain (Id) @ 25°C
  • 375A Tc
  • Gate Charge (Qg) (Max) @ Vgs
  • 300nC @ 10V
  • Drain to Source Voltage (Vdss)
  • 100V
  • Drive Voltage (Max Rds On,Min Rds On)
  • 10V
  • Vgs (Max)
  • ±20V
  • Continuous Drain Current (ID)
  • 375A
  • Threshold Voltage
  • 2.7V
  • Drain Current-Max (Abs) (ID)
  • 20A
  • Drain-source On Resistance-Max
  • 0.0035Ohm
  • Pulsed Drain Current-Max (IDM)
  • 500A
  • DS Breakdown Voltage-Min
  • 100V
  • Avalanche Energy Rating (Eas)
  • 260 mJ
  • REACH SVHC
  • No SVHC
  • RoHS Status
  • RoHS Compliant
  • Lead Free
  • Lead Free

Download datasheets and manufacturer documentation for INFINEON AUIRF7769L2TR.

Datasheets:

Other Related Documents:

PCN Assembly/Origin:

PCN Packaging:

ConflictMineralStatement:

AUIRF7769L2TR Description


AUIRF7769L2TR is a 100v Automotive DirectFET? Power MOSFET. The AUIRF7769L2TR combines the latest Automotive HEXFET? Power MOSFET Silicon technology with the advanced DirectFET? packaging to achieve the lowest on-state resistance in a package that has the footprint of a DPak (TO-252AA) and only 0.7 mm profile. The DirectFET? package is compatible with existing layout geometries used in power applications, PCB assembly equipment and vapor phase, and infra-red or convection soldering techniques when application note AN-1035 is followed regarding the manufacturing methods and processes.?



AUIRF7769L2TR Features


  • Advanced Process Technology

  • Exceptionally Small Footprint and Low Profile

  • High Power Density

  • Low Parasitic Parameters

  • Dual Sided Cooling

  • 175°C Operating Temperature

  • Repetitive Avalanche Capability for Robustness and Reliability

  • Lead free, RoHS and Halogen-free

  • Automotive Qualified



AUIRF7769L2TR Applications


  • Automotive Motor Drive

  • DC-DC

  • Other Heavy Load Applications

  • Cellular phones

  • Laptop computers
