Manufacturer No:

BAT41

Manufacturer:

ST

Package:

DO-204AH, DO-35, Axial

Description:

Schottky Diode Rectifier Small Signal =< 200mA (Io), Any Speed 450mV @ 1mA -65°C~125°C 100nA @ 50V 2-Termination Tape & Reel (TR) DO-204AH, DO-35, Axial Through Hole

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

BAT41 information

ST BAT41 technical specifications, attributes, parameters and parts with similar specifications to ST BAT41.

  • Type
  • Parameter
  • Lifecycle Status
  • ACTIVE (Last Updated: 7 months ago)
  • Factory Lead Time
  • 15 Weeks
  • Mount
  • Through Hole
  • Mounting Type
  • Through Hole
  • Package / Case
  • DO-204AH, DO-35, Axial
  • Number of Pins
  • 2
  • Weight
  • 4.535924g
  • Diode Element Material
  • SILICON
  • Packaging
  • Tape & Reel (TR)
  • JESD-609 Code
  • e3
  • Part Status
  • Active
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • Number of Terminations
  • 2
  • ECCN Code
  • EAR99
  • Terminal Finish
  • Matte Tin (Sn) - annealed
  • Max Operating Temperature
  • 125°C
  • Min Operating Temperature
  • -65°C
  • Additional Feature
  • FAST SWITCHING
  • HTS Code
  • 8541.10.00.70
  • Capacitance
  • 2pF
  • Subcategory
  • Rectifier Diodes
  • Voltage - Rated DC
  • 100V
  • Terminal Form
  • WIRE
  • Current Rating
  • 100mA
  • Pin Count
  • 2
  • Number of Elements
  • 1
  • Polarity
  • Standard
  • Power Dissipation-Max
  • 0.1W
  • Element Configuration
  • Single
  • Speed
  • Small Signal =< 200mA (Io), Any Speed
  • Diode Type
  • Schottky
  • Current - Reverse Leakage @ Vr
  • 100nA @ 50V
  • Output Current
  • 100mA
  • Voltage - Forward (Vf) (Max) @ If
  • 450mV @ 1mA
  • Case Connection
  • ISOLATED
  • Forward Current
  • 100mA
  • Max Reverse Leakage Current
  • 100nA
  • Operating Temperature - Junction
  • -65°C~125°C
  • Max Surge Current
  • 750mA
  • Current - Average Rectified (Io)
  • 100mA DC
  • Forward Voltage
  • 400mV
  • Max Reverse Voltage (DC)
  • 100V
  • Average Rectified Current
  • 100mA
  • Peak Reverse Current
  • 100nA
  • Max Repetitive Reverse Voltage (Vrrm)
  • 100V
  • Capacitance @ Vr, F
  • 2pF @ 1V 1MHz
  • Peak Non-Repetitive Surge Current
  • 750mA

Download datasheets and manufacturer documentation for ST BAT41.

Datasheets:

BAT41 Overview


Phase diode rectifier produces a maximum reverse leakage current of 100nA volts.As a result, this device has a rectified current of 100mA volts on average.Phase diode rectifier is permissible for forward current to reach 100mA.Fuse elements have an indefinite life expectancy of 100mA, which is the maximum current that the fuse can carry for an indefinite period of time.There is no maximum value for 750mA surge current.Phase diode rectifier is possible for a capacPhase diode rectifierance-based device to output a value of 2pF.Based on the data charts in the datasheets, the peak reverse is 100nA.
