ST BYW77P-200
Manufacturer No:
BYW77P-200
Manufacturer:
Package:
SOD-93-2
Description:
Standard Diode Rectifier Fast Recovery =< 500ns, > 200mA (Io) 1.15V @ 40A -40°C~150°C 25?A @ 200V 2-Termination Tube SOD-93-2 Through Hole
Quantity:
Delivery:
Payment:
In Stock :Available
Price not displayed? Please send an RFQ, and we will respond immediately.
BYW77P-200 information
ST BYW77P-200 technical specifications, attributes, parameters and parts with similar specifications to ST BYW77P-200.
- Type
- Parameter
- Mount
- Through Hole
- Mounting Type
- Through Hole
- Package / Case
- SOD-93-2
- Number of Pins
- 2
- Diode Element Material
- SILICON
- Packaging
- Tube
- Part Status
- Obsolete
- Moisture Sensitivity Level (MSL)
- 1 (Unlimited)
- Number of Terminations
- 2
- ECCN Code
- EAR99
- Max Operating Temperature
- 150°C
- Min Operating Temperature
- -40°C
- Additional Feature
- FREE WHEELING DIODE
- HTS Code
- 8541.10.00.80
- Subcategory
- Rectifier Diodes
- Voltage - Rated DC
- 200V
- Technology
- AVALANCHE
- Peak Reflow Temperature (Cel)
- NOT SPECIFIED
- Current Rating
- 25A
- Time@Peak Reflow Temperature-Max (s)
- NOT SPECIFIED
- Base Part Number
- BYW77
- Pin Count
- 2
- Qualification Status
- Not Qualified
- Number of Elements
- 1
- Speed
- Fast Recovery =< 500ns, > 200mA (Io)
- Diode Type
- Standard
- Current - Reverse Leakage @ Vr
- 25?A @ 200V
- Output Current
- 25A
- Voltage - Forward (Vf) (Max) @ If
- 1.15V @ 40A
- Case Connection
- CATHODE
- Forward Current
- 25A
- Operating Temperature - Junction
- -40°C~150°C
- Max Surge Current
- 500A
- Application
- EFFICIENCY
- Forward Voltage
- 1.15V
- Max Reverse Voltage (DC)
- 200V
- Average Rectified Current
- 25A
- Number of Phases
- 1
- Reverse Recovery Time
- 50 ns
- Peak Reverse Current
- 25?A
- Max Repetitive Reverse Voltage (Vrrm)
- 200V
- Peak Non-Repetitive Surge Current
- 500A
- Reverse Voltage
- 200V
- Max Forward Surge Current (Ifsm)
- 500A
- Recovery Time
- 50 ns
- REACH SVHC
- No SVHC
- RoHS Status
- RoHS Compliant
Download datasheets and manufacturer documentation for ST BYW77P-200.
BYW77P-200 Overview
There is no reason to reverse the voltage at 200V.Devices like this have an average rectified current of 25A volts.There is no limit to the forward current value.Having a current rating of 25A means it can carry the maximum current an indefinite period without deterioration.Surge current can reach maximum value 500A.On the data sheets, the peak reverse is indicated by the data chart as 25?A.
BYW77P-200 Features
an average rectified current of 25A volts
a current rating of 25A
the peak reverse is 25?A
BYW77P-200 Applications
There are a lot of STMicroelectronics
BYW77P-200 applications of single-phase diode rectifier.
- DC motor control and drives
- Battery chargers
- Welders
- Power converters
- Reverse Polarity Protection
- Ultra High-Speed Switching
- Freewheeling
- Polarity Protection Diode
- Recirculating Diode
- Switching Diode
