BROADCOM HDLG-3416

Manufacturer No:

HDLG-3416

Manufacturer:

BROADCOM

Package:

DIP

Description:

Description: Smart/Normal 5 X 7 Dot Matrix LED Display, 4-Character, Green, 6.86mm, DIP-22

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

HDLG-3416 information

BROADCOM HDLG-3416 technical specifications, attributes, parameters and parts with similar specifications to BROADCOM HDLG-3416.

Type
Parameter

RoHS Status
RoHS Compliant

Part Life Cycle Code
Active

Ihs Manufacturer
BROADCOM INC

Reach Compliance Code
compliant

HTS Code
8541.40.20.00

Factory Lead Time
24 Weeks

Samacsys Manufacturer
Avago Technologies

Additional Feature
BUILT-IN MEMORY, WITH DECODER/DRIVER

Color
GREEN

Color@Wavelength
Yellow

Configuration
COMPLEX

Display Height
6.86 mm

JESD-609 Code
e2

Number of Characters
4

Number of Functions
4

Operating Temperature-Max
85 °C

Operating Temperature-Min
-40 °C

Optoelectronic Device Type
5 X 7 DOT MATRIX LED DISPLAY

Peak Wavelength
568 nm

Terminal Finish
TIN COPPER

Download datasheets and manufacturer documentation for BROADCOM HDLG-3416.

HDLG-3416 Description

These are 5 x 7 dot matrix displays with four 0.27? tall characters, driven by an on-board CMOS IC. The IC stores and decodes 7 bit ASCII data and displays it with an easy to read 5 x 7 font. Multi-plexing circuitry and drivers are included in the IC to allow the display to interface simply with bus-based micro processor systems.

HDLG-3416 Features

?? Smart alphanumeric display

Built-in RAM, ASCII decoder, and LED drive circuitry

?? Software controlled dimming and blanking

?? 128 ASCII character set

?? End-stackable

?? Categorized for luminous intensity

? Yellow and Green categories for color

? Use of like categories yields a uniform display

?? Wide operating temperature range -40°C to +85°C

?? Wave solderable

?? Wide viewing angle (50° typical)

HDLG-3416 Applications

? Patient Monitoring

? Navigation Equipment

? Industrial Automation

? Portable Data Terminals
