Renesas ISL43231IRZ

Manufacturer No:

ISL43231IRZ

Manufacturer:

Renesas

Package:

QFN

Description:

QUAD Analog Switches BREAK-BEFORE-MAKE 20 Pins 5V QFN

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

ISL43231IRZ information

Renesas ISL43231IRZ technical specifications, attributes, parameters and parts with similar specifications to Renesas ISL43231IRZ.

Type
Parameter

Mount
Surface Mount

Package / Case
QFN

Number of Pins
20

Packaging
Bulk

Published
2003

JESD-609 Code
e3

Pbfree Code
yes

Part Status
Active

Moisture Sensitivity Level (MSL)
3 (168 Hours)

Number of Terminations
20

Resistance
50Ohm

Terminal Finish
MATTE TIN

Max Operating Temperature
85°C

Min Operating Temperature
-40°C

Subcategory
Multiplexer or Switches

Technology
CMOS

Terminal Position
QUAD

Peak Reflow Temperature (Cel)
260

Number of Functions
3

Supply Voltage
5V

Terminal Pitch
0.5mm

Time@Peak Reflow Temperature-Max (s)
30

Output
SEPARATE OUTPUT

Pin Count
20

Number of Channels
2

Max Supply Voltage
12V

Min Supply Voltage
2V

Analog IC - Other Type
SINGLE-ENDED MULTIPLEXER

Operating Supply Current
7?A

Max Supply Current
7?A

Number of Bits
3

Throw Configuration
SPDT

Turn On Delay Time
35 ns

Supply Type
Dual, Single

Neg Supply Voltage-Nom (Vsup)
-5V

Turn-Off Delay Time
22 ns

Max Dual Supply Voltage
6V

Min Dual Supply Voltage
2V

Dual Supply Voltage
5V

Off-state Isolation-Nom
92 dB

On-state Resistance Match-Nom
1.3Ohm

Switching
BREAK-BEFORE-MAKE

Switch-on Time-Max
50ns

Drain to Source Resistance
39Ohm

Length
4mm

Height Seated (Max)
1mm

Width
4mm

Download datasheets and manufacturer documentation for Renesas ISL43231IRZ.

Datasheets:

intersil-isl43231irz-datasheets-5228.pdf

ISL43231IRZ Overview

Packed in QFN, the electronic component is convenient for shipping overseas. Advanced packaging method Bulk is used to provide high reliability. There are 20 terminations totally. By its 2 channels, the electronic component provides high-quality output. With a 5V voltage supply, the electrical component should be turned on and run. 20 pins are injected to the electronic part body. This digital multiplexer has 50Ohm internal resistance. Please refer to the datasheets for 20 pins functions. This switch device is a typical Multiplexer or Switches. In a normalsituation, users should not supply the switches with voltage higher than 12V. A cost-effective Dual, Single supply type analogue multiplexer. The lowest voltage fed to the electronic component should be 2V. 7?A current would be enough for this multiplexer to operate. If put voltage greater than 7?A on the device, damage may be caused to the analogue multiplexer. Dual supply volatge is feasible for this multiplexer. But it should not go beyond 6V. You should attach at least 2V voltage if you are using dual power supply. Integrated with SINGLE-ENDED MULTIPLEXER analog IC. This analog switch ic utilizes SEPARATE OUTPUT output. The switches should not operate in an environment where the temperature is higher than 85°C. This electronic component presents a Drain to Source resistance of 39Ohm. It is able to conduct in a 3-bit way.

ISL43231IRZ Features

2 Channels
7?A Supply Current
Drain-to-Source resistance: 39Ohm
3-Bit

ISL43231IRZ Applications

There are a lot of Intersil (Renesas Electronics America)
ISL43231IRZ Analog Switches & Multiplexers ICs applications.

High-Voltage
Transmit
Low-Voltage
Isolation
Medical
Imaging
Ultrasound
Audio and video switching
Automatic test equipment
Precision data acquisition
