Harwin M22-5330605
Harwin M22-5330605

Harwin M22-5330605

Manufacturer No:

M22-5330605

Manufacturer:

Harwin

Package:

SIL

Description:

M22 Series 1-Row Header, Cuttable Solder Brass Bulk Surface Mount, Right Angle Gold Polyamide (PA6T), Nylon 6T 6-Position Board to Board or Cable 0.079 2.00mm Height

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

M22-5330605 information

Harwin M22-5330605 technical specifications, attributes, parameters and parts with similar specifications to Harwin M22-5330605.

  • Type
  • Parameter
  • Factory Lead Time
  • 13 Weeks
  • Contact Material
  • Brass
  • Mount
  • Surface Mount
  • Mounting Type
  • Surface Mount, Right Angle
  • Package / Case
  • SIL
  • Contact Shape
  • Square
  • Insulation Material
  • Polyamide (PA6T), Nylon 6T
  • Housing Material
  • Nylon
  • Operating Temperature
  • -40°C~105°C
  • Packaging
  • Bulk
  • Series
  • M22
  • Published
  • 2011
  • JESD-609 Code
  • e4
  • Pbfree Code
  • yes
  • Part Status
  • Active
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • Termination
  • Solder
  • ECCN Code
  • EAR99
  • Connector Type
  • Header, Cuttable
  • Number of Positions
  • 6
  • Number of Rows
  • 1
  • Gender
  • Male
  • Additional Feature
  • ROHS COMPLIANT
  • Fastening Type
  • Push-Pull
  • Contact Finish - Mating
  • Gold
  • MIL Conformance
  • NO
  • DIN Conformance
  • NO
  • IEC Conformance
  • NO
  • Filter Feature
  • NO
  • Contact Type
  • Male Pin
  • Mixed Contacts
  • NO
  • Option
  • GENERAL PURPOSE
  • Current Rating (Amps)
  • 2A per Contact
  • Total Number of Contacts
  • 6
  • Orientation
  • Right Angle
  • Depth
  • 8.6mm
  • Insulation Height
  • 0.079 2.00mm
  • Style
  • Board to Board or Cable
  • Number of Positions Loaded
  • All
  • Pitch - Mating
  • 0.079 2.00mm
  • Number of Conductors
  • ONE
  • Reference Standard
  • UL
  • Reliability
  • COMMERCIAL
  • Shrouding
  • Unshrouded
  • Number Of PCB Rows
  • 1
  • Lead Pitch
  • 2mm
  • Contact Length - Mating
  • 0.165 4.20mm

Download datasheets and manufacturer documentation for Harwin M22-5330605.

Datasheets:

M22-5330605 Overview


Currently, it is packaged in Header, Cuttable.The mounting type of the device is Surface Mount, Right Angle.A Bulk case is used to package the product.A product of the M22 Series, it belongs to the range of products of that series.Furthermore, there are other features available, such as ROHS COMPLIANT, to name a few.SIL means there is a device enclosed in the packaging.Surface Mount represents the mounting point for the part.-40°C~105°C Operating Temperature is the default operating temperature for the device.
