DIODES MB3510

Manufacturer No:

MB3510

Manufacturer:

DIODES

Package:

4-Square, MB

Description:

Single Phase Bridge Rectifier Standard QC Terminal -55°C~150°C TJ 10?A @ 1000V 1.2V @ 17.5A 4-Termination 1-Phase 4-Square, MB Bulk

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

MB3510 information

DIODES MB3510 technical specifications, attributes, parameters and parts with similar specifications to DIODES MB3510.

Type
Parameter

Mount
Screw

Mounting Type
QC Terminal

Package / Case
4-Square, MB

Number of Pins
35

Diode Element Material
SILICON

Operating Temperature
-55°C~150°C TJ

Packaging
Bulk

Published
2006

JESD-609 Code
e3

Part Status
Obsolete

Moisture Sensitivity Level (MSL)
1 (Unlimited)

Number of Terminations
4

Terminal Finish
Matte Tin (Sn)

Subcategory
Bridge Rectifier Diodes

Technology
Standard

Terminal Position
UPPER

Terminal Form
SOLDER LUG

Peak Reflow Temperature (Cel)
260

Reach Compliance Code
not_compliant

Time@Peak Reflow Temperature-Max (s)
40

Base Part Number
MB3510

Pin Count
4

JESD-30 Code
S-MUFM-D4

Qualification Status
Not Qualified

Element Configuration
Single

Diode Type
Single Phase

Current - Reverse Leakage @ Vr
10?A @ 1000V

Voltage - Forward (Vf) (Max) @ If
1.2V @ 17.5A

Case Connection
ISOLATED

Forward Current
35A

Forward Voltage
1.2V

Number of Phases
1

Peak Reverse Current
10?A

Max Repetitive Reverse Voltage (Vrrm)
1kV

Peak Non-Repetitive Surge Current
400A

RoHS Status
RoHS Compliant

Download datasheets and manufacturer documentation for DIODES MB3510.

Datasheets:

diodesincorporated-mb251f-datasheets-2610.pdf

MB3510 Overview

Bridge rectifier has 4 pins.Powered by a forward voltage of 35A, this device operates on a forward voltage of 35A.By using the base part number MB3510, we can identify a number of related components.Basically, it is a 4-Square, MB package-type electronic component.There is no mounting method for the device.At -55°C~150°C TJ, it operates normally.For powering this device, there is a peak reverse voltage of 10?A.

MB3510 Features

4 pin count
35A forward voltage
forward voltage of 35A
4-Square, MB package
operating at a temperature of -55°C~150°C TJ
peak reverse voltage of 10?A
a reverse voltage peak of 10?A

MB3510 Applications

There are a lot of Diodes Incorporated
MB3510 applications of bridge rectifiers.

Electrically isolated aluminum case
Motor controls ? Low Voltage and Medium Voltage converters
SCR power bridges for solid state starters
SCR and diode based input rectifiers
Crowbar systems for motor drives
Wind power (alternative energy) ? Converters available as diodes, SCRs or IGBTs
Transportation ? Traction rectifiers and auxiliary rectifiers
Inductive heating ? Input rectifiers
Welding systems ? Input rectifiers and fast recovery diodes
Uninterruptible power supplies ? SCR transfer switches and input rectifiers
