Manufacturer No:

NSR20F30NXT5G

Manufacturer:

ONSEMI

Package:

2-XDFN

Description:

Schottky Barrier Diode, 30 V, 2.0 A, Low I<sub>R</sub>

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

NSR20F30NXT5G information

ONSEMI NSR20F30NXT5G technical specifications, attributes, parameters and parts with similar specifications to ONSEMI NSR20F30NXT5G.

  • Type
  • Parameter
  • Package Type
  • DSN-2
  • MSL Temp (°C)
  • 260
  • IRM Max (µA)
  • 20
  • IFSM Max (A)
  • 28
  • VF Max (V)
  • 0.48
  • Cj Max (pF)
  • -
  • Case Outline
  • 152AB
  • MSL Type
  • 1
  • Container Qty.
  • 5000
  • Configuration
  • Single
  • VRRM Min (V)
  • 30
  • Container Type
  • DSFTP
  • trr Max (ns)
  • -
  • IO(rec) Max (A)
  • 2

Download datasheets and manufacturer documentation for ONSEMI NSR20F30NXT5G.

Datasheet:

Package Drawing:

The Schottky diode is optimized for low forward voltage drop and low leakage current and are offered in a Chip Scale Package (CSP) to reduce board space. The low thermal resistance enables designers to meet the challenging task of achieving higher efficiency and meeting reduced space requirements.

Application

  • LCD and Keypad Backlighting
  • Buck and Boost dc-dc converters
  • Reverse Voltage and Current Protection

End Product

  • GPS Systems
  • Consumer/Portable Products
  • Notebooks PCs & PDAs

Feature

  • Very Low Forward Voltage Drop (VF)
  • Low Reverse Current (IR)
  • High ESD Ratings: HMB(3B), MM(C)
  • 2.0 A of continuous forward current
