Manufacturer No:

PHPT61003NYX

Manufacturer:

NEXPERIA

Package:

SC-100, SOT-669

Description:

NPN 175°C TJ 100nA ICBO 1 Elements 4 Terminations SILICON NPN SC-100, SOT-669 Tape & Reel (TR) Surface Mount

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

PHPT61003NYX information

NEXPERIA PHPT61003NYX technical specifications, attributes, parameters and parts with similar specifications to NEXPERIA PHPT61003NYX.

  • Type
  • Parameter
  • Factory Lead Time
  • 8 Weeks
  • Contact Plating
  • Tin
  • Mount
  • Surface Mount
  • Mounting Type
  • Surface Mount
  • Package / Case
  • SC-100, SOT-669
  • Number of Pins
  • 5
  • Transistor Element Material
  • SILICON
  • Operating Temperature
  • 175°C TJ
  • Packaging
  • Tape & Reel (TR)
  • Published
  • 2015
  • Part Status
  • Active
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • Number of Terminations
  • 4
  • Max Power Dissipation
  • 25W
  • Terminal Position
  • SINGLE
  • Terminal Form
  • GULL WING
  • Base Part Number
  • PHPT61003N
  • Pin Count
  • 4
  • Reference Standard
  • AEC-Q101; IEC-60134
  • JESD-30 Code
  • R-PSSO-G4
  • Number of Elements
  • 1
  • Configuration
  • SINGLE
  • Case Connection
  • COLLECTOR
  • Power - Max
  • 1.25W
  • Polarity/Channel Type
  • NPN
  • Transistor Type
  • NPN
  • Collector Emitter Voltage (VCEO)
  • 100V
  • Max Collector Current
  • 3A
  • DC Current Gain (hFE) (Min) @ Ic, Vce
  • 80 @ 1A 10V
  • Current - Collector Cutoff (Max)
  • 100nA ICBO
  • Vce Saturation (Max) @ Ib, Ic
  • 330mV @ 300mA, 3A
  • Collector Emitter Breakdown Voltage
  • 100V
  • Transition Frequency
  • 140MHz
  • Collector Emitter Saturation Voltage
  • 150mV
  • Max Breakdown Voltage
  • 100V
  • Frequency - Transition
  • 140MHz
  • Collector Base Voltage (VCBO)
  • 100V
  • Emitter Base Voltage (VEBO)
  • 7V
  • Continuous Collector Current
  • 3A
  • REACH SVHC
  • No SVHC
  • RoHS Status
  • RoHS Compliant

Download datasheets and manufacturer documentation for NEXPERIA PHPT61003NYX.

Datasheets:

PCN Packaging:

RohsStatement:

PHPT61003NYX Overview


This device has a DC current gain of 80 @ 1A 10V, which is the ratio between the base current and the collector current.This design offers maximum flexibility with a collector emitter saturation voltage of 150mV.A VCE saturation (Max) of 330mV @ 300mA, 3A means Ic has reached its maximum value(saturated).Continuous collector voltages should be kept at 3A to achieve high efficiency.A high level of efficiency can be achieved if the base voltage of the emitter remains at 7V.As you can see, the part has a transition frequency of 140MHz.A breakdown input voltage of 100V volts can be used.A maximum collector current of 3A volts is possible.

PHPT61003NYX Features


the DC current gain for this device is 80 @ 1A 10V
a collector emitter saturation voltage of 150mV
the vce saturation(Max) is 330mV @ 300mA, 3A
the emitter base voltage is kept at 7V
a transition frequency of 140MHz


PHPT61003NYX Applications


There are a lot of Nexperia USA Inc.
PHPT61003NYX applications of single BJT transistors.


  • Inverter
  • Interface
  • Driver
  • Muting
