Manufacturer No:

STY139N65M5

Manufacturer:

ST

Package:

TO-247-3

Description:

MOSFET (Metal Oxide) N-Channel Tube 17m ? @ 65A, 10V ±25V 15600pF @ 100V 363nC @ 10V TO-247-3

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

STY139N65M5 information

ST STY139N65M5 technical specifications, attributes, parameters and parts with similar specifications to ST STY139N65M5.

  • Type
  • Parameter
  • Lifecycle Status
  • ACTIVE (Last Updated: 7 months ago)
  • Factory Lead Time
  • 12 Weeks
  • Contact Plating
  • Tin
  • Mount
  • Through Hole
  • Mounting Type
  • Through Hole
  • Package / Case
  • TO-247-3
  • Number of Pins
  • 247
  • Transistor Element Material
  • SILICON
  • Operating Temperature
  • 150°C TJ
  • Packaging
  • Tube
  • Series
  • MDmesh? V
  • Part Status
  • Active
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • Number of Terminations
  • 3
  • ECCN Code
  • EAR99
  • Resistance
  • 17mOhm
  • Technology
  • MOSFET (Metal Oxide)
  • Base Part Number
  • STY139
  • JESD-30 Code
  • R-PSIP-T3
  • Number of Elements
  • 1
  • Number of Channels
  • 1
  • Power Dissipation-Max
  • 625W Tc
  • Element Configuration
  • Single
  • Operating Mode
  • ENHANCEMENT MODE
  • Turn On Delay Time
  • 295 ns
  • FET Type
  • N-Channel
  • Transistor Application
  • SWITCHING
  • Rds On (Max) @ Id, Vgs
  • 17m ? @ 65A, 10V
  • Vgs(th) (Max) @ Id
  • 5V @ 250?A
  • Input Capacitance (Ciss) (Max) @ Vds
  • 15600pF @ 100V
  • Current - Continuous Drain (Id) @ 25°C
  • 130A Tc
  • Gate Charge (Qg) (Max) @ Vgs
  • 363nC @ 10V
  • Rise Time
  • 56ns
  • Drive Voltage (Max Rds On,Min Rds On)
  • 10V
  • Vgs (Max)
  • ±25V
  • Fall Time (Typ)
  • 37 ns
  • Turn-Off Delay Time
  • 295 ns
  • Continuous Drain Current (ID)
  • 130A
  • Gate to Source Voltage (Vgs)
  • 25V
  • Drain to Source Breakdown Voltage
  • 650V
  • Pulsed Drain Current-Max (IDM)
  • 520A
  • Avalanche Energy Rating (Eas)
  • 2400 mJ
  • Max Junction Temperature (Tj)
  • 150°C
  • Height
  • 24.6mm
  • Length
  • 15.9mm
  • Width
  • 5.3mm
  • Radiation Hardening
  • No

Download datasheets and manufacturer documentation for ST STY139N65M5.

Datasheets:

STY139N65M5 Description


The STY139N65M5 is an N-channel MDmesh V Power MOSFET that combines STMicroelectronics' well-known PowerMESH horizontal layout structure with an inventive, patented vertical production method. The resulting product is especially well suited for applications that need excellent power density and exceptional efficiency because to its extraordinarily low on-resistance, which is unmatched among silicon-based Power MOSFETs.



STY139N65M5 Features


  • Easy to drive

  • Higher VDSSrating

  • 100% avalanche tested

  • Higher dv/dt capability

  • Excellent switching performance

  • Max247 worldwide best RDS(on)



STY139N65M5 Applications


  • Industrial

  • Automotive

  • Communications equipment
