Manufacturer No:

VS-10BQ100HM3/5BT

Manufacturer:

VISHAY

Package:

DO-214AA, SMB

Description:

Schottky Diode Rectifier Fast Recovery =< 500ns, > 200mA (Io) 750mV @ 1A -55°C~175°C 500μA @ 100V 2-Termination Bulk DO-214AA, SMB Surface Mount

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

VS-10BQ100HM3/5BT information

VISHAY VS-10BQ100HM3/5BT technical specifications, attributes, parameters and parts with similar specifications to VISHAY VS-10BQ100HM3/5BT.

  • Type
  • Parameter
  • Factory Lead Time
  • 11 Weeks
  • Mount
  • Surface Mount
  • Mounting Type
  • Surface Mount
  • Package / Case
  • DO-214AA, SMB
  • Diode Element Material
  • SILICON
  • Packaging
  • Bulk
  • Series
  • Automotive, AEC-Q101
  • Published
  • 2017
  • JESD-609 Code
  • e3
  • Part Status
  • Active
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • Number of Terminations
  • 2
  • ECCN Code
  • EAR99
  • Terminal Finish
  • Matte Tin (Sn)
  • Additional Feature
  • FREE WHEELING DIODE
  • Terminal Position
  • DUAL
  • Terminal Form
  • C BEND
  • Peak Reflow Temperature (Cel)
  • 260
  • Reach Compliance Code
  • not_compliant
  • Time@Peak Reflow Temperature-Max (s)
  • 40
  • JESD-30 Code
  • R-PDSO-C2
  • Operating Temperature (Max)
  • 175°C
  • Number of Elements
  • 1
  • Configuration
  • SINGLE
  • Diode Type
  • Schottky
  • Current - Reverse Leakage @ Vr
  • 500μA @ 100V
  • Voltage - Forward (Vf) (Max) @ If
  • 750mV @ 1A
  • Operating Temperature - Junction
  • -55°C~175°C
  • Voltage - DC Reverse (Vr) (Max)
  • 100V
  • Max Reverse Voltage (DC)
  • 100V
  • Average Rectified Current
  • 1A
  • Capacitance @ Vr, F
  • 65pF @ 5V 1MHz
  • RoHS Status
  • RoHS Compliant

Download datasheets and manufacturer documentation for VISHAY VS-10BQ100HM3/5BT.

Datasheets:

RohsStatement:

VS-10BQ100HM3/5BT Overview


As a result, this device has a rectified current of 1A volts on average.

VS-10BQ100HM3/5BT Features


an average rectified current of 1A volts


VS-10BQ100HM3/5BT Applications


There are a lot of Vishay Semiconductor Diodes Division
VS-10BQ100HM3/5BT applications of single-phase diode rectifier.


  • DC motor control and drives
  • Battery chargers
  • Welders
  • Power converters
  • Reverse Polarity Protection
  • Ultra High-Speed Switching
  • Freewheeling
  • Polarity Protection Diode
  • Recirculating Diode
  • Switching Diode
