LITTELFUSE Z85C3008VSG

Manufacturer No:

Z85C3008VSG

Manufacturer:

LITTELFUSE

Package:

44-LCC (J-Lead)

Description:

1.27mm 5V Specialized Interface IC Z85C30 44 Pin 8MHz 5V 44-LCC (J-Lead)

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

Z85C3008VSG information

LITTELFUSE Z85C3008VSG technical specifications, attributes, parameters and parts with similar specifications to LITTELFUSE Z85C3008VSG.

Type
Parameter

Factory Lead Time
13 Weeks

Mount
Surface Mount

Mounting Type
Surface Mount

Package / Case
44-LCC (J-Lead)

Number of Pins
44

Weight
2.386605g

Packaging
Tube

Published
1996

JESD-609 Code
e3

Pbfree Code
yes

Part Status
Active

Moisture Sensitivity Level (MSL)
3 (168 Hours)

Number of Terminations
44

ECCN Code
EAR99

Terminal Finish
Matte Tin (Sn)

Max Operating Temperature
70°C

Min Operating Temperature
0°C

Additional Feature
TWO MODEM CONTROL I/OS USABLE AS GENERAL PURPOSE I/OS; 10 X 19 FRAME STATUS FIFO

HTS Code
8542.31.00.01

Subcategory
Other Microprocessor ICs

Technology
CMOS

Voltage - Supply
4.5V~5.5V

Terminal Position
QUAD

Terminal Form
J BEND

Terminal Pitch
1.27mm

Frequency
8MHz

Base Part Number
Z85C30

Pin Count
44

Power Supplies
5V

Temperature Grade
COMMERCIAL

Interface
Bus

Operating Supply Current
4mA

uPs/uCs/Peripheral ICs Type
SERIAL IO/COMMUNICATION CONTROLLER, MULTI PROTOCOL

Supply Current-Max
12mA

Data Rate
5 Mbps

Boundary Scan
NO

Low Power Mode
NO

RAM (words)
0

Number of Serial I/Os
2

Bus Compatibility
Z80

Communication Protocol
ASYNC, BIT; SYNC, BYTE; SYNC, HDLC; SYNC, SDLC; X.25; BISYNC; EXT SYNC

Data Encoding/Decoding Method
NRZ; NRZI-SPACE; BIPH-MARK(FM1); BIPH-SPACE(FM0); BIPH-LEVEL(MANCHESTER)

Height
3.86mm

Length
16.66mm

Width
16.66mm

REACH SVHC
Unknown

Radiation Hardening
No

Download datasheets and manufacturer documentation for LITTELFUSE Z85C3008VSG.

Datasheets:

zilog-z85c3008vsg-datasheets-0580.pdf

zilog-z85c3008vsg-datasheets-0581.pdf

zilog-z85c3008vsg-datasheets-0582.pdf

Z85C3008VSG Overview

It is appropriate for the device to use the 44-LCC (J-Lead) package.The package contains a Tube case.Surface Mount is used to install this component.It is possible to find devices that supply 4.5V~5.5V volts.Using the Z85C30 can help you find related parts.It has 44 terminations.It is recommended that you set this device to 5V.44 pins are on it in total.In order to operate, we use the 44 pins.The mount is Surface Mount.It is designed to work at a minimum working temperature of 0°C to ensure reliability.In order to maintain consistency, a maximum value of 70°C is recommended.Electronic components are of the Other Microprocessor ICs family.This device consists of SERIAL IO/COMMUNICATION CONTROLLER, MULTI PROTOCOL UPs, UCs, or peripheral ICs.The device can deliver voltage at 5V volts.This device is also capable of finding TWO MODEM CONTROL I/OS USABLE AS GENERAL PURPOSE I/OS; 10 X 19 FRAME STATUS FIFO.When operating at a frequency of 8MHz , it is capable of achieving good performance.Currently, it has 2 serial I/O ports.

Z85C3008VSG Features

It is based on Z85C30.
Set the part at 5V volts
SERIAL IO/COMMUNICATION CONTROLLER, MULTI PROTOCOL of uPs/uCs/Peripheral ICs Type
Run frequency at 8MHz
Number of Serial I/Os : 2

Z85C3008VSG Applications

There are a lot of Zilog
Z85C3008VSG Specialized Interface ICs applications.

Precision data acquisition
Battery-powered systems
Sample-and-hold systems
Communication systems
Data Acquisition Systems
Relay Replacement
Battery Powered Systems
Existing multiplexer applications (both fault-protected and
nonfault-protected)
New designs requiring multiplexer functions
